MegaChip8: Technical Reference #

This is still work in progress, I put together the information I could think of as relevant so far, but I bet I missed something. Also there sure is room for improvement. Feedback is welcome.

Quick Links #

• Original MEGA-CHIP-8 Reference
• Modern MegaChip Reference

What is MEGA-CHIP-8? #

First of all for this to be a useful reference, I need to address the elephant in the room: What is MEGA-CHIP-8?

Historically MEGA-CHIP-8 is a CHIP-8 variant specified in 2007 by Martijn Wanting, Revival-Studios, when they released the SDK for it. The megachip10.txt document describes their vision of MEGA-CHIP-8. They also released an emulator ⎋ RS-M8001 as binary only, for Windows, and a few demos and a game based on MEGA-CHIP-8. Sadly, the behavior of that emulator is not agreeing with the specification from the SDK, and also the SDK contains elements with question marks that seem to not be finalized. No update to either the emulator or the SDK has been made since 2007, afaik.

Then there is ⎋ Mega-8, imho the second implementation of MEGA-CHIP-8, done by Ready4Next in 2014. They filled in some gaps and implemented blending, contrary to the original RS-M8001. They also added new scrolling behavior to MEGA-CHIP-8 that wasn’t defined in the SDK, but used it in a nice tech demo to show off the features of their implementation.

This got us a few questions short of a complete specification. In October 2022, Ninja Weedle and I decided to take a stab at it, we tried out a lot of stuff and wrote test programs. We came up with a common understanding of enough of the behavior of a MEGA-CHIP implementation to get us started. Ninja Weedle thankfully documented the findings at his ⎋ MegaChip8 GitHub repository.

From there on, over the years multiple people contributed to the task and added their expectations and implemented their understanding of MEGA-CHIP-8 in their own emulators.

All this leads to the current situation, that we currently have/had at least 7 different implementations of MEGA-CHIP-8, and they do not agree in every detail with each other. The scope of this reference is, to document as much of a common behavior, based on the original SDK, as possible. With this reference, one should be able to implement a MEGA-CHIP-8 interpreter, but more importantly, one should be able to write a MEGA-CHIP-8 program that runs on all of them.

So for any part that seems under-defined or ambiguous, keep in mind that the mission of this reference is to define common ground while leaving wiggle room for the different implementations. Maybe we can agree on a hard specification for all aspects one day, but this will be hopefully is as good as it gets for now.

This attempt of making a reference for MEGA-CHIP-8 is threefold:

1. A minimal safe MEGA-CHIP-8 that is common to existing implementations, including RS-M8001.
2. An attempt to specify something coined Modern-MegaChip, which is a variant that implements the hinted but originally unimplemented features of the MEGA-CHIP-8 SDK document. There are multiple Modern-MegaChip implementations now, that should conform to this.
3. Beyond Modern-MegaChip, that is a look at the different approaches to fill gaps in the SDK and make a more powerful MEGA-CHIP-8. These are not supported by all implementations, but specific to some or one of them.

Throughout this document, I try to use the term MEGA-CHIP-8 when I refer to the original behavior of the RS-M8001 by Revivial-Studios, and Modern-MegaChip when I refer to the more feature-complete and extended behavior. I use the term MEGA-CHIP (without the 8) in general, to more broadly refer to any MEGA-CHIP implementation.

If you want to make a new MEGA-CHIP game, I recommend to stick to 1 (MEGA-CHIP-8) if you don’t need the features of Modern-MegaChip. That way even the original interpreter can run it, and just for breacking ground, it imho deserves additional games.

If you want blending, or scrolling, or more than 1 MB of RAM, then Modern-MegaChip is for you. And of course, if you can always make a game specific to your or an existing implementation, this reference is not for policing, but for finding common ground where possible. 😉

A Original MEGA-CHIP-8: Technical Reference #

This is MEGA-CHIP-8 as in RS-M8001, the megachip.exe by Rivival-Studios, also documenting discrepancies between the SDK document megachip10.txt and the actual behavior of the Windows 32bit binary.

A.1 Overview #

MEGA-CHIP‑8 is derived from SUPER-CHIP and was released in 2007 as a Windows executable with a few example programs.

Following this spec as a game programmer, gives a game that runs on that original Windows based emulator and should work on all other MEGA-CHIP implementations too. If you are making a new MEGA-CHIP implementation, you should try to support this minimal subset mode.

RS-M8001: There are a few very quirky aspects in RS-M8001 that are explained in added boxes like this, but emulating those should not be a goal and relying on them in a new program is not recommended. Many could be considered bugs.

It defines a virtual machine with:

• about 1 MB of addressable memory (0x00000–0xFFFFF).
• Sixteen 8‑bit general‑purpose registers V0...VF.
• One 24‑bit index register I as an index into the ram.
• Two 8‑bit timers (DT, the delay timer, ST the sound timer) that count down at 50Hz, which also is the used frame rate.
• Three graphics modes: Lores 2-color 64×32, hires 2-color 128×64 and the actual MEGA-CHIP mode with 256×192 pixels in 256 colors.
• Sprite sizes up to 256x256 pixels.
• A typical hexadecimal keypad with 16 keys (0–F).
• A buzzer that allows to emit a fixed frequency tone of varying duration, but also mono 8-bit sample playback.
• Execution speed is 25IPF in lores, 50IPF in enxtended/hires mode, and 5000IPF in MegaChip mode.

All CHIP-8 programs are loaded at memory location 0x200, where the interpreter begins execution after a reset.

RS-M8001: Note that the original emulator does not support accessing ram below 0x200. The emulated ram actually starts at 0x200, bad things will happen if you try to access ram below that. I would not recomment to replicate that in a new implementation, but new games should not access ram below 0x200.

A.2 Virtual Machine Model #

A.2.1 State #

For the definition of the state, the following table uses the types:

• uint8 = 8-bit unsigned integer
• uint16 = 16-bit unsigned integer

Choose the types that match this best for your chosen language.

The MEGA-CHIP-8 VM/interpreter has the following state:

¹⁾ Stack pointer SP and program counter PC are internal registers of the interpreter, and in-accessible to a MEGA-CHIP-8 program. The model suggested here is the most common approach to implement them, but stack could also be a stack-container if the chosen language offers one, and in that case the stack pointer would be omitted (it’s the size of the container). The program counter could also be a pointer into the ram or an iterator. However, in that case common protection mechanisms against out-of-bounds access, like using masking to ensure the valid range, would need to be implemented using range checks. It also makes it harder to generate trace logs that are comparable to existing trace logs, so one should be aware of this, when not using the standard approach.

Execution speed is 25IPF in lores, 50IPF in enxtended/hires mode, and 5000IPF in MegaChip mode.

A.2.2 Memory Layout #

MEGA-CHIP-8 is specified as having 16MB of ram, but the original emulator only offers 1MB, so if one wants to make sure a program is able to run on all MEGA-CHIP implementations, it’s best to limit your program to short of 1MB.

Neither stack nor the screen are inside that reachable ram.

As in all CHIP-8 variants of the knowledge base, the execution range of the program is limited to 0xFFF, as all instructions allowing to influence the program counter are limited to 12 bit parameters.

RS-M8001: Just to repeat this from the intro: The original emulator does not support accessing ram below 0x200. The emulated ram actually starts at 0x200, bad things will happen if you try to access ram below that. I would not recomment to replicate that in a new implementation, but new games should not access ram below 0x200.

A.2.3 Timers #

• Both timers are unsigned 8‑bit counters.
• When set to a non‑zero value they decrement automatically at originally 50 Hz, synced to the screen updates
• Some modern implementations use 60 Hz instead of 50 Hz.

A.2.4 Sound #

MEGA-CHIP-8 still has support for the buzzer sound of CHIP-8/SUPER-CHIP. Buzzing is active while ST > 0, and as implementor of a CHIP-8 interpreter you can freely decide on a pitch or waveform to your liking. Be aware to decrement the timers ideally at the start of the video frame and not right after the opcode execution of a frame, as then the delay or buzzing will be shorter by one frame. Delays or beeps of length 1 will even have no effect, and setting delay to 1 is a very common pattern to pace a game.

The main new feature is a mono 8-bit sample playback. The audio is represented by unsigned 8-bit samples that need the following memory layout:

Sample playback is triggered by the opcode 060n and stopped by the opcode 0700. The parameter n of the opcode 060n is ignored in original MEGA-CHIP-8, so the sample run and loop until stopped by 0700. So to write a games using sample playback and be compatible with even RS-M8001, remember to stop playback by 0700 at some point.

A.2.5 Graphics #

MEGA-CHIP-8 contains two mostly independent graphics paths. As long as the program stays outside of MegaChip mode, it uses a CHIP-8/SCHIP-compatible 1bpp framebuffer. When MegaChip mode is enabled, drawing switches to the 256×192 indexed-color MegaChip framebuffer.

A.2.5.1 Non-MegaChip Mode #

When MegaChip mode is disabled, graphics are monochrome and use a 1bpp framebuffer. The screen can be in lores or SCHIP extended/hires mode:

00FE disables SCHIP extended mode and switches to lores, 00FF enables SCHIP extended/hires mode. These opcodes change the SCHIP mode flag and the current framebuffer size, but not the MegaChip mode flag.

Dxyn draws an 8×n sprite from memory at I. Drawing is XORed into the 1bpp framebuffer, and VF is set to 1 if any drawn bit collides with an already-set display bit. Otherwise VF is set to 0.

The origin is wrapped, but the horizontal part of the sprite is not really clipped or wrapped. If a sprite row continues past the right edge, it continues into the pixels left in the row below. Vertical clipping only happens at the bottom.

Dxy0 is only a drawing instruction while SCHIP extended/hires mode is active. In lores mode it performs no drawing, and VF is not cleared or updated because the draw routine is not called.

In hires mode, Dxy0 draws a 16×16 monochrome sprite from I. The sprite consumes 32 bytes, stored as two bytes per row for 16 rows. Drawing is XORed into the packed 1bpp framebuffer.

Coordinates for Dxy0 are wrapped for the sprite origin:

x = Vx & 0x7f
y = Vy & 0x3f

The destination row stride is 16 bytes, matching the 128×64 SCHIP framebuffer. There is an original off-by-one vertical clipping quirk: row 63 is never reached by a Dxy0 sprite, so it clips one line early.

A.2.5.2 MegaChip Mode #

MegaChip mode is enabled with 0011 and disabled with 0010. When enabled, drawing switches from the packed 1bpp non-MegaChip framebuffer to a 256x192 8bpp framebuffer.

framebuffer: 256 * 192 bytes
pixel value: palette index

Dxyn writes palette indices into this framebuffer. RGB conversion happens only when the frame is presented, using the current MegaChip palette. Changing the palette after drawing changes the displayed colors of already-drawn pixels.

A.2.5.2.1 Palette #

02nn loads nn palette entries from memory pointed to by index register I.

Entry 0 is not loaded by 02nn; entry 255 is forced to white after every palette load. Usable programmable entries are effectively 1..254.

A.2.5.2.2 Sprites #

03nn sets MegaChip sprite width. 04nn sets MegaChip sprite height.

03nn: sprite width  = nn, or 256 if nn == 0
04nn: sprite height = nn, or 256 if nn == 0

In MegaChip mode, normal Dxyn ignores n and draws a width * height 8bpp sprite from memory at I.

0      transparent
1..255 drawn as palette index

Drawing in MegaChip mode is direct replacement, not XOR. Coordinates are not wrapped; pixels outside 0..255, 0..191 are clipped/skipped.

A.2.5.2.3 Collision #

09nn sets the MegaChip collision color index. Dxyn clears VF, then sets it if a drawn nonzero source pixel replaces a destination pixel equal to the collision color, provided the source pixel is not also the collision color.

if dst == collision_color and src != collision_color:
    VF = 1

A.2.5.2.4 Font Drawing #

After Fx29 or Fx30, the next Dxyn in MegaChip mode draws from the built-in font table instead of memory. Set font bits are drawn with palette index 255, in white.

width  = 8
height = n
color  = 255

This source choice is controlled by a temporary font flag. Dxyn clears the flag afterward, so a second Dxyn requires another Fx29 or Fx30 to draw a font sprite again.

A.2.5.2.5 Mode Mixing Warning #

00FE/00FF and 0010/0011 change different flags but share screen-size globals. Mixing SCHIP hires opcodes with MegaChip mode can produce inconsistent states. In particular, SCHIP scroll opcodes operate on the old 1bpp buffer, not the MegaChip framebuffer.

A.3 Instruction Format #

• Most instructions are 16 bit (2 bytes), stored big‑endian (high byte first). There is an additional long index load instruction (01mm mmmm) that is used to load the index register with an address beyond the 12bit range.
• The original SDK documentation describes that there needs to be a NOP after that long index load, but that is not really correctly describing what is going on: The NOP is an artifact of the assembler being patched in a way that still supports only 16 bit opcodes, and so it uses the space of the NOP instruction to fill with the remaining 16 bit of the address. Modern Assemblers like the Octo derived Chiplet do not have this restriction, only the Windows-only SDK assembler has.
• The most significant nibble can still be used to derive the primary opcode class; the remaining nibbles supply operands or further opcode distinction.

For this reference the naming convention is following the one used in the original CHIP-8 documentation, but using lowercase letters for better distinction from the opcode defining nibbles:

After fetch, the PC normally is incremented by 2 and jump-, branch-, or skip-instructions modify it explicitly.

A.4 Original MEGA-CHIP-8 Opcode Set #

The table below enumerates every opcode supported or documented by MEGA-CHIP-8.

^*) The original MegaChip implementation supports an optional “compatibility mode” that allows to run CHIP-8 programs on MEGA-CHIP-8. If enabled it basically switches the following quirks to original CHIP-8 behavior:

• 8xy6 and 8xyE copy the value of Vy into Vx before the operation
• Fx55 and Fx65 increment I by x+1 instead of not changing I
• Dxyn in non-MegaChip mode ends the frame (basically display wait)

A.4.0 Specific Notes on Opcodes #

Some opcodes have some strange behavior or side effects that can be important to understand, when writing software for MegaChip that should support the original MEGA-CHIP-8 interpreter. It might also be useful when implementing a MegaChip emulator/interpreter. The observed details where researched partly using the original MEGA-CHIP-8 interpreter’s code and making a behavior replicating implementation of the original interpreter.

A.4.1 Mode changes: 0010/0011/00FE/00FF #

The original interpreter has some “issues” regarding the clean separation of the SuperCHIP mode and the MegaChip mode.

The short version one should remember is, that one should not use 0010/0011 to enable/disable the MegaChip mode while in the SuperCHIP mode, and one should not use 00FE/00FF to enable/disable the SuperCHIP mode while in the MegaChip mode.

The long version: The original interpreter separates the modes badly. Internally it has:

• A megaChipMode flag indicating if the MegaChip mode is enabled or not.
• A superChipMode flag indicating if the SuperCHIP mode is enabled or not.
• Two variables containing the width and height of the current framebuffer.

The individual mode change opcodes now do the following:

• 0011 sets the megaChipMode to enabled, and the framebuffer size to 256x192.
• 0010 sets the megaChipMode to disabled, and the framebuffer size to 64x32.
• 00FF sets the superChipMode to enabled, and the framebuffer size to 128x64.
• 00FE sets the superChipMode to disabled, and the framebuffer size to 64x32.

Neither of the mode-pairs influences the flag of the other mode!

Some consequences:

• 00E0 clears the corresponding framebuffer depending on the megaChipMode flag, but uses the set current framebuffer size, so if 00FF was called after 0011, it only erases a 128x64 part of the MegaChip screen. Still the display update uses a hard coded 256x192 when megaChipMode is enabled.
• Dxyn for CHIP-8/SCHIP mode uses the superChipMode flag to determine the wrapping/stride logic of the screen but with the 64x32 screen size when 0010 was called after a 00FF leading to a 128x64/64x32 mixup that can even lead to OOB access and potentially a crash.
• 00Bn, 00Cn, 00FB and 00FC are not checking for the mode flags at all, so they always work on the 1bpp buffer of CHIP-8/SCHIP, but use the current framebuffer size. Scrolling after switching on the MegaChip mode is heavily OOB-writing and a good way to crash the emulator.

A.4.2 Loading a Palette with 02kk #

The 02kk loads a color list into the MegaChip palette. The operand is the number of colors to load. Each color is stored as four bytes in memory:

A R G B

Palette loading starts at entry 1, not entry 0, so color 0 is always transparent black. Also color 255 is forced to be opaque white after loading the palette.

RS-M8001: If no palette load has occurred since reset, entry 255 may still be zero/black. Just usint 0200 while not loading any palette, will be enough to enforce the opaque white color at index 255.

A.4.3 Setting the index register with Ammm and 01nn nnnn, Fx29 and Fx30 #

The fact that the original MEGA-CHIP-8 does not emulate the ram below 0x200 leads to some special handling related to the index register. Setting it to a font sprite with Fx29 or Fx30 will set a font flag that triggers the special Dxyn behavior. The same happens when setting the index register with Ammm to an address below 0x100. It does not happen with 01nn nnnn when setting an address below 0x100. So after that Dxyn will not draw in font mode. Also changing the index register with Fx1E will not change the font flag.

Additionally any address between 0x100..0x1ff set with Ammm and any address below 0x200 set with 01nn nnnn will lead to the index register pointing to sone OOB internal data structures of the emulator. Not to actual MegaChip memory. Writing to that via Fx33 or Fx55 or Fx75 can have bad consequences and leads to undefined behavior.

A.4.4 Drawing Dxy0 in non-MegaChip mode #

In non-MegaChip mode, Dxy0 is only a drawing instruction while SCHIP extended mode is active.

When in lores mode, Dxy0 performs no drawing at all, same as the classic VIP version, and VF is not cleared or updated by the draw routine because the draw routine is not called.

When in hires/extended mode, Dxy0 draws a 16x16 monochrome sprite from I. The sprite consumes 32 bytes: two bytes per row, 16 rows total. Drawing is XORed into the packed 1bpp chip-screen framebuffer, and VF is set to 1 if any drawn bit collides with an already-set display bit. Otherwise VF is 0.

Coordinates are wrapped for the sprite origin:

x = Vx & 0x7f
y = Vy & 0x3f

The destination row stride is 16 bytes, matching the 128x64 SCHIP framebuffer.

Vertical clipping has an original off-by-one quirk. Before drawing, the emulator computes:

height = 16
if y + 16 > 63:
height = 63 - y

As a result the bottom row, row 63, is never reached by a Dxy0 sprite, and it clips one line early.

Horizontal handling does not clip. The origin is wrapped to 0..127, but the 16-pixel row is continuing in the pixels left, one line below, so neither clipping nor real wrapping happens.

A.4.5 Drawing Dxyn in non-MegaChip mode #

Horizontal handling does not clip. The origin is wrapped to 0..127, but the subsequent sprite row is continuing in the pixels left, one line below, so neither clipping nor real wrapping happens. Clipping only happens at the bottom.

A.4.6 Drawing Dxyn in MegaChip mode #

When MegaChip mode is enabled with 0011, the Dxyn instruction no longer uses the normal CHIP-8/SCHIP 1-bit XOR sprite path. Instead, it draws into the MegaChip 256-color index based framebuffer.

The draw position is taken from Vx and Vy. Coordinates are not wrapped. Pixels outside the 256x192 MegaChip framebuffer are clipped or skipped.

For normal MegaChip bitmap drawing, the low nibble n of Dxyn is ignored. The sprite dimensions come from the MegaChip sprite-size registers instead:

• 03kk set sprite width
• 04kk set sprite height

A value of 0 for either dimension means 256.

The sprite data starts at index register I. Each byte is one pixel and is interpreted as a palette index:

• 0 is transparent, does not modify the framebuffer
• 1..255 drawn as that palette index

Drawing is not XOR. A nonzero source pixel replaces the destination pixel.

Collision is controlled by the MegaChip collision color, set by 09nn. Before drawing, VF is cleared. For each nonzero source pixel that is inside the framebuffer, the emulator checks:

if destination_pixel == collision_color
   and source_pixel != collision_color:
   VF = 1

The pixel is then written to the framebuffer. Collision does not count transparent source pixels.

The implementation clips horizontally and vertically against the 256x192 framebuffer.

For columns beyond x=255, source bytes are still consumed but no pixel is written. For rows beyond y=191, the row is skipped and the original implementation does not consume source bytes for that skipped row.

If index register I was set to a hex digit font bitmap by using either Fx29 or Fx30, the original implementation sets a “font” flag and MegaChip mode uses a special font drawing path.

In that case Dxyn draws an 8-pixel-wide monochrome font sprite into the MegaChip framebuffer using palette index 255. Only set font bits are drawn. Unset bits are transparent. Since palette entry 255 is forced to white after any 02kk palette-load instruction, these font sprites normally appear white.

RS-M8001: If no palette load has occurred since reset, entry 255 may still be zero/black.

RS-M8001: The “font” flag is reset by the Dxyn instruction, so subsequent Dxyn calls will draw a MegaChip color sprite with index register I pointing to the font sprite offset plus 0x200 (so for Fx29 it is Vx*5+0x200 and for Fx30 it is Vx*10+0x250)

The 080n blend mode and 05kk alpha/fade opcodes are documented, but the recovered draw routine for Dxyn itself performs a direct framebuffer write for nonzero pixels. No blending or alpha is supported.

A.4.7 Key handling with Ex9E and ExA1 #

The ocpodes work as expected for any value in Vx as long as it is below 16. The original interpreter does not check for the key array bounds, and does not mask the value, so key numbers 16 and beyond lead to undefined behavior.

A.4.8 Waiting for a Key with Fx0A in MegaChip mode #

Due to the fact that MegaChip mode updates the screen content on 00E0 using Fx0A will not show any draws done between the last 00E0 and the Fx0A call. So on the original interpreter, one needs to show whatever information the user should see to know what keys to press, erase the screen with 00E0 to force an update, and then use Fx0A to wait for the user to press a key.

Also the original MEGA-CHIP-8 interpreter does wait inside the opcode handler, explicitly calling an event handling, so while input works in that loop, the timers are not decrementing, they stop until a key was released and only then continue to count down.

Modern-MegaChip: Modern implementations follow the lead from Mega-8 and update the screen on Fx0A. This leads to an incompatibility, as the original needs a clear first, so nothing is shown on the modern MegaChip emulator if the program was made for the original RS-M8001.

A.4.9 Fx75 / Fx85 #

In original MEGA-CHIP-8, the Fx75 and Fx85 opcodes have the same behavior as the Fx55 and Fx65 opcodes, they are just not influenced by the compatibility mode and never change the index register I.

B Modern-MegaChip: Technical Reference #

B.1 Overview #

As one can see from the section about the original RS-M8001 MEGA-CHIP-8 implementation, there are a bunch of really quirky details and unimplemented features in it. But the SDK documentation, though compact and lacking detail, makes one wonder what a fully functional MegaChip implementation might have looked like.

When we tried to understand MegaChip and implement it into our emulators, we started to fill in the gaps. A major contributor to what modern MegaChip would be sure is Mega-8. With the MegaTestDemo and the implementation by Mega-8, a first MegaChip emulator already existed that supported blending. So its implementation of the MegaChip blending and the features used in the demo were the base. From there we explored how to support the MegaTechDemo in our own implementations and semi-agreed on a set of features that modern MegaChip should support.

Like the original MEGA-CHIP-8, modern MegaChip is derived from SUPER-CHIP or SCHIP. The original MEGA-CHIP has some issues in its SCHIP mode, and as Mega-8 is mostly doing a modern SCHIP as fallback, it is also the recommended way to implement the SCHIP opcodes in MegaChip.

B.2 Virtual Machine Model #

B.2.1 State #

For the definition of the state, the following table uses the types:

• uint8 = 8-bit unsigned integer
• uint16 = 16-bit unsigned integer

Choose the types that match this best for your chosen language.

The modern MegaChip VM/interpreter has the following state:

¹⁾ Stack pointer SP and program counter PC are internal registers of the interpreter, and in-accessible to a modern MegaChip program. The model suggested here is the most common approach to implement them, but stack could also be a stack-container if the chosen language offers one, and in that case the stack pointer would be omitted (it’s the size of the container). The program counter could also be a pointer into the ram or an iterator. However, in that case common protection mechanisms against out-of-bounds access, like using masking to ensure the valid range, would need to be implemented using range checks. It also makes it harder to generate trace logs that are comparable to existing trace logs, so one should be aware of this, when not using the standard approach.

B.2.2 Memory Layout #

Modern MegaChip supports 16MB of ram. The normal CHIP-8 font is places at offset 0x0000. The 10 lines high big font introduced by SCHIP is placed at offset 0x0050. This is not a hard requirement but a common recommendation.

Neither stack nor the screen are inside that reachable ram.

As in all CHIP-8 variants of the knowledge base, the execution range of the program is limited to 0xFFF, as all instructions allowing to influence the program counter are limited to 12 bit parameters.

B.2.3 Timers #

• Both timers are unsigned 8‑bit counters.
• When set to a non‑zero value they decrement automatically at originally 50 Hz, synced to the screen updates
• Some modern implementations use 60 Hz instead of 50 Hz.

B.2.4 Sound #

Modern MegaChip still has support for the buzzer sound of CHIP-8/SUPER-CHIP. Buzzing is active while ST > 0, and as implementor of a CHIP-8 interpreter you can freely decide on a pitch or waveform to your liking. Be aware to decrement the timers ideally at the start of the video frame and not right after the opcode execution of a frame, as then the delay or buzzing will be shorter by one frame. Delays or beeps of length 1 will even have no effect, and setting delay to 1 is a very common pattern to pace a game.

The main new feature is a mono 8-bit sample playback. The audio is represented by unsigned 8-bit samples that need the following memory layout:

Sample playback is triggered by the opcode 060n and stopped by the opcode 0700. The parameter n of the opcode 060n, that is ignored original MEGA-CHIP-8, is used to signal a one-shot playback. To stay compatible with the original and Mega-8, a value of 0 signals a looped playback, so the sample run and loop until stopped by 0700. A value of 1 signals a one-shot playback, where the playback stops when the end of the sample is reached.

B.2.5 Graphics #

Modern MegaChip contains two mostly independent graphics paths. As long as the program stays outside of MegaChip mode, it uses a modern SCHIP-like 1bpp framebuffer. When MegaChip mode is enabled, drawing switches to the 256×192 indexed-color MegaChip framebuffer.

B.2.5.1 Non-MegaChip Mode #

When MegaChip mode is disabled, graphics are monochrome and use the modern SCHIP behavior. The screen can be in lores or hires mode:

00FE disables hires mode and switches to lores, 00FF enables hires mode. Both mode changes clear the screen.

Dxyn draws an 8×n sprite from memory at I. Drawing is XORed into the framebuffer, and VF is set to 1 if any drawn pixel changes from set to unset. If that never happens, VF is set to 0.

Dxy0 always draws a 16×16 sprite, independent of the current resolution. The sprite consumes 32 bytes, stored as two bytes per row for 16 rows.

Scrolling uses logical pixels of the current resolution:

• 00Bn scrolls the screen up by n pixels.
• 00Cn scrolls the screen down by n pixels.
• 00FB scrolls the screen right by four pixels.
• 00FC scrolls the screen left by four pixels.

There is no display wait in non-MegaChip mode.

B.2.5.2 MegaChip Mode #

MegaChip mode is enabled with 0011 and disabled with 0010. When enabled, drawing switches from the packed 1bpp non-MegaChip framebuffer to a 256x192 resolution. In contrast to the original MEGA-CHIP-8 implementation, to support blending and the “scrolling feature” introduced by Mega-8, a set of multiple buffers is needed:

• Collision-Buffer: A framebuffer: 256 * 192 bytes, pixel value: palette index
• Back-Buffer: Used for the current ongoing sprite drawing: 256 * 192, pixel value: RGBA8 color (actual channel order is implementation defined)
• Front-Buffer: 00E0 pushes the back-buffer here for presentation: 256 * 192, pixel value: RGBA8 color (actual channel order is implementation defined)
• A display texture used to draw the actual screen content in the emulators UI, 256 * 192 pixels, whatever your screen format is.

Dxyn writes palette indices into this framebuffer. It also writes the RGBA from the palette of the corresponding pixels. During this drawing the blend mode is in effect. The following blend modes (set by 080n) are supported:

• 0=normal, is all original MEGACHIP-8 supports, just overwrite the framebuffer value with the color of the new pixel
• 1=25%, blend 25% of the sprite pixel color with 75% of the framebuffer color
• 2=50%, blend 50% of the sprite pixel color with 50% of the framebuffer color
• 3=75%, blend 75% of the sprite pixel color with 25% of the framebuffer color
• 4=additive, add the channels of the sprite pixel to those of the framebuffer color, clamping at 255
• 5=multiply, multiply the channels of the sprite pixel with those of the framebuffer color, clamping at 255

Changing the palette after drawing, does not change the displayed colors of already-drawn pixels, contrary to the original MEGA-CHIP-8 implementation.

The normal display process is that each 00E0 (or timeout of the frame, if the ipf is reached) pushes the back-buffer content into front-buffer (you can also swap them and clear the then new back-buffer, the actual solution is up to you). The front-buffer is then translated into the display texture and displayed in the emulators UI. The reason for the two buffers is to implement the “scrolling feature” introduced by Mega-8.

B.2.5.2.1 Scrolling in MegaChip Mode #

Mega-8 introduced a “scrolling feature” that uses the regular scrolling opcodes (00Bn, 00Cn, 00FB, 00FC) to scroll the front-buffer (the framebuffer that was pushed/swapped last) by the given amount or 4 pixels (in case of 00FB and 00FC). Then the display texture is updated by merging the front-buffer with the back-buffer wherever the front-buffer is transparent. This merge is then displayed.

B.2.5.2.2 Palette #

02nn loads nn palette entries from memory pointed to by index register I.

Entry 0 is not loaded by 02nn; entry 255 is forced to white after every palette load. Usable programmable entries are effectively 1..254.

Contrary to the original MEGA-CHIP-8 implementation, entry 255 is recommended to be initialized white on reset. Entry 0 is always black transparent.

B.2.5.2.3 Sprites #

03nn sets MegaChip sprite width. 04nn sets MegaChip sprite height.

03nn: sprite width  = nn, or 256 if nn == 0
04nn: sprite height = nn, or 256 if nn == 0

In MegaChip mode, normal Dxyn ignores n and draws a width * height 8bpp sprite from memory at I.

0      transparent
1..255 drawn as palette index

Drawing in MegaChip mode is direct replacement, not XOR. Coordinates are not wrapped; pixels outside 0..255, 0..191 are clipped/skipped.

B.2.5.2.4 Collision #

09nn sets the MegaChip collision color index. Dxyn clears VF, then sets it if a drawn nonzero source pixel replaces a destination pixel equal to the collision color, provided the source pixel is not also the collision color.

if dst == collision_color and src != collision_color:
    VF = 1

B.2.5.2.5 Font Drawing #

After Fx29 or Fx30, the next Dxyn in MegaChip mode, Dxyn draws from the font address. Set font bits are drawn with palette index 255, white.

width  = 8
height = n
color  = 255

The recommendation is for this source choice to be controlled by the sprite address being below 0x100, instead of a volatile flag, still it is recommended to use Fx29 or Fx30 again for each font digit, even if it is the same, to be compatible to flag based implementations.

B.2.5.2.6 Mode Mixing Warning #

Due to the issues with mixing modes in the original implementation, it is strongly suggested to not enable MegaChip mode when in hires SCHIP mode, and to not enable hires SCHIP mode when in MegaChip mode. As long as the modes are used independently, all should be good.

B.3 Instruction Format #

• Most instructions are 16 bit (2 bytes), stored big‑endian (high byte first). There is an additional long index load instruction (01mm mmmm) that is used to load the index register with an address beyond the 12bit range.
• The original SDK documentation describes that there needs to be a NOP after that long index load, but that is not really correctly describing what is going on: The NOP is an artifact of the assembler being patched in a way that still supports only 16 bit opcodes, and so it uses the space of the NOP instruction to fill with the remaining 16 bit of the address. Modern Assemblers like the Octo derived Chiplet do not have this restriction, only the Windows-only SDK assembler has.
• The most significant nibble can still be used to derive the primary opcode class; the remaining nibbles supply operands or further opcode distinction.

For this reference the naming convention is following the one used in the original CHIP-8 documentation, but using lowercase letters for better distinction from the opcode defining nibbles:

After fetch, the PC normally is incremented by 2 and jump-, branch-, or skip-instructions modify it explicitly.

B.4 Modern MegaChip Opcode Set #

The table below enumerates every opcode supported or documented by MEGA-CHIP-8.

This basically means the common quirks are set to

• No VF reset on 8xy1/8xy2/8xy3
• Only Shift Vx
• Fx55/Fx65 don’t change I
• Sprites clip by default, but a wrapping quirk should be available (needed for MegaTestDemo)
• Bxkk jumps to xkk + Vx
• Dxyn has a display wait in non-MegaChip lores mode

B.4.1 Specific Notes on Existing Modern MegaChip Implementations #

Mega8 by Ready4Next #

• Mega8 can will draw a width of only a multiple of 8 when in MegaChip mode. Having a sprite with e.g. a width of 20 will only draw rows of 16 pixels, but it still uses the correct width to calculate the next row of sprite data in memory, so the sprites look mostly correct but get clipped at the right side. Modern MegaChip does not inherit this flaw, but if one wants to write a game that also supports Mega8, one should pad the sprites with transparent pixels to ensure compatibility.

Known Implementations of MEGA-CHIP #

In order of release (as known to me):

If you know any other MEGA-CHIP implementations, please let me know, these are still rare beasts and I want to know them all! 😉

Acknowledgements #

The current information about MEGA-CHIP-8 is a community effort of #chip-8 on the EmuDev Discord server. I want to especially thank @NinjaWeedle for his groundwork and writing a bunch of tests. Also thanks to @JanitorRaus, @ZXDunny, @ArkoSammy12 and all the others that took part in various discussions and test sessions to gain further insights.
