SUPER-CHIP: Technical Reference #

(A compact, implementation-level description of SUPER-CHIP, suitable for both program authors and emulator writers that want to implement the calculator variants and still understand where the more common modern behavior differs.)

You know CHIP-8 and are only interested in a compact description of the differences? Jump to the TLDR section.

1 Overview #

SUPER-CHIP is not a single perfectly clean target, but a small family of closely related CHIP-8 extensions. The common part is based on CHIP-48 behavior and adds an extended 128×64 display mode, some mode-control opcodes, a 16×16/8×16 draw, and persistent register storage.

The sub-variants described here are:

• SUPER-CHIP v1.0 (BETA), an early version with a different Fx29 big-font behavior.
• SUPER-CHIP v1.0, which adds Fx30 for big-font lookup.
• SUPER-CHIP v1.1, which adds scrolling and changes the Fx55/Fx65 index behavior.
• Modern SUPER-CHIP, the simplified behavior based on Octo, and often what modern tools mean when they say “SCHIP”.

The common calculator versions define a virtual machine with:

• 4kB of addressable memory (0x000-0xFFF).
• Sixteen 8-bit general-purpose registers V0...VF.
• One 16-bit index register I as an index into the ram.
• Two 8-bit timers (DT, the delay timer, ST the sound timer) that count down at 64Hz.
• A two-color display that can switch between 64×32 lores and 128×64 extended/hires mode.
• A hexadecimal keypad with 16 keys (0-F).
• A buzzer controlled by the sound timer.
• A small persistent storage area for up to eight registers.

All SUPER-CHIP programs are loaded at memory location 0x200, where the interpreter begins execution after a reset.

2 Virtual Machine Model #

2.1 State #

For the definition of the state, the following table uses the types:

• uint8 = 8-bit unsigned integer
• uint16 = 16-bit unsigned integer
• bool = true/false value

Choose the types that match this best for your chosen language.

The SUPER-CHIP VM/interpreter has the following state:

Stack pointer SP and program counter PC are internal registers of the interpreter, and in-accessible to a SUPER-CHIP program. The model suggested here is the most common approach to implement them, but stack could also be a stack-container if the chosen language offers one, and in that case the stack pointer would be omitted (it’s the size of the container).

2.2 Memory Layout #

A generic SUPER-CHIP implementation has 4k ram organized in bytes with a memory layout like this:

0x000-0x04F   built-in small SUPER-CHIP font
0x050-0x0EF   build-in big font
0x0F0-0x1FF   unused
0x200-0xFFF   Program / working RAM

The largest practical SUPER-CHIP program size is 3583 bytes. The range from 0x200 to 0xFFF contains 3584 bytes, but a program actually using all of them would make the interpreter crash.

As in all CHIP-8 variants of the knowledge base, the execution range of the program is limited to 0xFFF, as all instructions allowing to influence the program counter are limited to 12 bit parameters.

2.3 Timers #

• Both timers are unsigned 8-bit counters.
• On the calculator variants they decrement automatically at 64 Hz, synced to the calculator frame rate.
• Modern SUPER-CHIP uses 60 Hz instead.

2.4 Sound #

For generic SUPER-CHIP the sound timer enables a simple sound output. Sound is active while ST > 0, and as implementor of a SUPER-CHIP interpreter you can freely decide on a pitch or waveform to your liking.

Be aware to decrement the timers ideally at the start of the video frame and not right after the opcode execution of a frame, as then the delay or buzzing will be shorter by one frame. Delays or beeps of length 1 will even have no effect, and setting delay to 1 is a very common pattern to pace a game.

2.5 Graphics #

The physical calculator display is 131×64 pixels. In extended mode, the 128×64 interpreter screen leaves three columns at the right edge of the LCD unused. In lores mode, the 64×32 interpreter screen is drawn as 2×2 LCD pixels per CHIP-8 pixel.

Generic SUPER-CHIP emulation does not need to expose those physical LCD details, especially if the screen is cleared on mode changes. They become relevant if one wants to emulate the original lores half-pixel scrolling and drawing artifacts.

Drawing #

Dxyn draws 8×n pixel graphics like CHIP-8, using data from memory at I, and leaves I unchanged.

Dxy0 is new in SUPER-CHIP:

• In lores mode on the calculator, it draws 8×16 pixels.
• In extended/hires mode, it draws 16×16 pixels.
• The 16×16 data is stored in row order, with two bytes per row.

In lores mode on the calculator variants there is a display wait, so a generic interpreter should break out of the frame execution loop after a draw instruction when extended mode is off. In extended/hires mode, there is no display wait. Modern SUPER-CHIP has no display wait in either mode.

NOTE:
Most generic SUPER-CHIP emulators clear the screen on mode change. Also the detail of drawing lores as 2x2 doesn’t need to be emulated if the screen is cleared on mode change, as no artifacts can be visible.

Legacy SCHIP Drawing:
On the calculator, the actual lores 2×2-drawing routine works a bit unusual: It draws the pattern into the even display rows doubling the pixels, and collision detection works on any of those two “sub-pixels” of each doubled pixel. Then it copies 32 hires pixels, starting from the hiresSpritePosX & 0x70 to the odd row. This can lead to changes in the odd rows outside the border of the actual drawn pattern.

This is only relevant for the combination of a mode change from hires to lores without clearing the screen, as only that way artifacts can be visible. No known-to-me game or non-test program makes use of this, so emulating this is more of a fun historic challenge than solving a real problem.

2.6 Font Set #

The regular or small font of SUPER-CHIP is at address 0x0000 and made of this patterns (same as CHIP-48):

It’s made up of these 16 characters:

The data for easy use in an emulator:

    0xF0, 0x90, 0x90, 0x90, 0xF0,  // 0
    0x20, 0x60, 0x20, 0x20, 0x70,  // 1
    0xF0, 0x10, 0xF0, 0x80, 0xF0,  // 2
    0xF0, 0x10, 0xF0, 0x10, 0xF0,  // 3
    0x90, 0x90, 0xF0, 0x10, 0x10,  // 4
    0xF0, 0x80, 0xF0, 0x10, 0xF0,  // 5
    0xF0, 0x80, 0xF0, 0x90, 0xF0,  // 6
    0xF0, 0x10, 0x20, 0x40, 0x40,  // 7
    0xF0, 0x90, 0xF0, 0x90, 0xF0,  // 8
    0xF0, 0x90, 0xF0, 0x10, 0xF0,  // 9
    0xF0, 0x90, 0xF0, 0x90, 0x90,  // A
    0xE0, 0x90, 0xE0, 0x90, 0xE0,  // B
    0xF0, 0x80, 0x80, 0x80, 0xF0,  // C
    0xE0, 0x90, 0x90, 0x90, 0xE0,  // D
    0xF0, 0x80, 0xF0, 0x80, 0xF0,  // E
    0xF0, 0x80, 0xF0, 0x80, 0x80   // F

NOTE:
Load the fonts into memory on every reset (as the previous program run could have modified them).

2.7 Input (Hex Keypad) #

The keypad consists of 16 keys labeled 0-F. Key states are queried by opcodes Ex9E, ExA1, and Fx0A.

The opcodes Ex9E and ExA1 only use the lower 4 bits of Vx. So a value greater than 15 is not an error here, the upper 4 bits are ignored. For Fx29/Fx30, see the sub-variant sections.

3 Instruction Format #

• All instructions are 16 bit (2 bytes), stored big-endian (high byte first).
• The most significant nibble determines the primary opcode class; the remaining nibbles supply operands or further opcode distinction.

For this reference the naming convention is following the one used in the original CHIP-8 documentation, but using lowercase letters for better distinction from the opcode defining nibbles:

After fetch, the PC normally is incremented by 2 and jump-, branch-, or skip-instructions modify it explicitly.

4 Common SUPER-CHIP Opcode Set #

The table below enumerates the common SUPER-CHIP opcode set. The following section adds the sub-variant specific differences.

NOTE:
The Fx75/Fx85 instructions have no hard established way of persistence outside of the calculator, so they could be kept in a static array, surviving emulator resets, or in a global file. The latter can be ROM-specific or shared.

5 Sub-Variants #

5.1 SUPER-CHIP v1.0 (BETA) #

The BETA version differs from the common SUPER-CHIP behavior in these places:

Big Font Data (8×10) #

    0x3c, 0x7e, 0xc3, 0xc3, 0xc3, 0xc3, 0xc3, 0xc3, 0x7e, 0x3c, // big 0
    0x18, 0x38, 0x58, 0x18, 0x18, 0x18, 0x18, 0x18, 0x18, 0x3c, // big 1
    0x3e, 0x7f, 0xc3, 0x06, 0x0c, 0x18, 0x30, 0x60, 0xff, 0xff, // big 2
    0x3c, 0x7e, 0xc3, 0x03, 0x0e, 0x0e, 0x03, 0xc3, 0x7e, 0x3c, // big 3
    0x06, 0x0e, 0x1e, 0x36, 0x66, 0xc6, 0xff, 0xff, 0x06, 0x06, // big 4
    0xff, 0xff, 0xc0, 0xc0, 0xfc, 0xfe, 0x03, 0xc3, 0x7e, 0x3c, // big 5
    0x3e, 0x7c, 0xc0, 0xc0, 0xfc, 0xfe, 0xc3, 0xc3, 0x7e, 0x3c, // big 6
    0xff, 0xff, 0x03, 0x06, 0x0c, 0x18, 0x30, 0x60, 0x60, 0x60, // big 7
    0x3c, 0x7e, 0xc3, 0xc3, 0x7e, 0x7e, 0xc3, 0xc3, 0x7e, 0x3c, // big 8
    0x3c, 0x7e, 0xc3, 0xc3, 0x7f, 0x3f, 0x03, 0x03, 0x3e, 0x7c  // big 9

5.2 SUPER-CHIP v1.0 #

SUPER-CHIP v1.0 moves the big-font lookup to Fx30 and lets Fx29 behave like in CHIP-8:

Big Font Data (8×10) #

SUPER-CHIP v1.0 uses the same big font data as the BETA version:

    0x3c, 0x7e, 0xc3, 0xc3, 0xc3, 0xc3, 0xc3, 0xc3, 0x7e, 0x3c, // big 0
    0x18, 0x38, 0x58, 0x18, 0x18, 0x18, 0x18, 0x18, 0x18, 0x3c, // big 1
    0x3e, 0x7f, 0xc3, 0x06, 0x0c, 0x18, 0x30, 0x60, 0xff, 0xff, // big 2
    0x3c, 0x7e, 0xc3, 0x03, 0x0e, 0x0e, 0x03, 0xc3, 0x7e, 0x3c, // big 3
    0x06, 0x0e, 0x1e, 0x36, 0x66, 0xc6, 0xff, 0xff, 0x06, 0x06, // big 4
    0xff, 0xff, 0xc0, 0xc0, 0xfc, 0xfe, 0x03, 0xc3, 0x7e, 0x3c, // big 5
    0x3e, 0x7c, 0xc0, 0xc0, 0xfc, 0xfe, 0xc3, 0xc3, 0x7e, 0x3c, // big 6
    0xff, 0xff, 0x03, 0x06, 0x0c, 0x18, 0x30, 0x60, 0x60, 0x60, // big 7
    0x3c, 0x7e, 0xc3, 0xc3, 0x7e, 0x7e, 0xc3, 0xc3, 0x7e, 0x3c, // big 8
    0x3c, 0x7e, 0xc3, 0xc3, 0x7f, 0x3f, 0x03, 0x03, 0x3e, 0x7c  // big 9

5.3 SUPER-CHIP v1.1 #

SUPER-CHIP v1.1 adds scrolling and changes the index behavior of the register load/store instructions:

Dxy0/Dxyn in hires on the calculator has the special collision behavior that VF contains the number of rows where a collision happened plus the number of rows clipped at the bottom border.

NOTE:
The special collision behavior is not implemented in Octo, or most of the generic SUPER-CHIP emulators, and it can trip some programs. Best make it an option/quirk and allow regular collision reporting via 0/1 in VF.

Big Font Data (8×10) #

    0x3C, 0x7E, 0xE7, 0xC3, 0xC3, 0xC3, 0xC3, 0xE7, 0x7E, 0x3C, // big 0
    0x18, 0x38, 0x58, 0x18, 0x18, 0x18, 0x18, 0x18, 0x18, 0x3C, // big 1
    0x3E, 0x7F, 0xC3, 0x06, 0x0C, 0x18, 0x30, 0x60, 0xFF, 0xFF, // big 2
    0x3C, 0x7E, 0xC3, 0x03, 0x0E, 0x0E, 0x03, 0xC3, 0x7E, 0x3C, // big 3
    0x06, 0x0E, 0x1E, 0x36, 0x66, 0xC6, 0xFF, 0xFF, 0x06, 0x06, // big 4
    0xFF, 0xFF, 0xC0, 0xC0, 0xFC, 0xFE, 0x03, 0xC3, 0x7E, 0x3C, // big 5
    0x3E, 0x7C, 0xE0, 0xC0, 0xFC, 0xFE, 0xC3, 0xC3, 0x7E, 0x3C, // big 6
    0xFF, 0xFF, 0x03, 0x06, 0x0C, 0x18, 0x30, 0x60, 0x60, 0x60, // big 7
    0x3C, 0x7E, 0xC3, 0xC3, 0x7E, 0x7E, 0xC3, 0xC3, 0x7E, 0x3C, // big 8
    0x3C, 0x7E, 0xC3, 0xC3, 0x7F, 0x3F, 0x03, 0x03, 0x3E, 0x7C  // big 9

5.4 Modern SUPER-CHIP #

Modern SUPER-CHIP is based on the SUPER-CHIP behavior of the Octo implementation. The idea is to leave out the most exotic parts of the original calculator variants and simplify the implementation.

The differences to SUPER-CHIP v1.1 are:

• Framerate and timer frequency are 60Hz.
• Mode changes (00FE and 00FF) always clear the screen.
• 00Cn scrolls down by n logical pixels of the current resolution, so no half-pixel scrolling in lores mode.
• 00FB and 00FC scroll right or left by four logical pixels.
• Dxy0 always draws 16×16 pixels, even when not in extended/hires mode.
• There is no display wait in either mode.

For a generic emulator this is usually the easiest SCHIP mode to expose as a default, but it is not the same as the calculator variants described above.

6 Main Loop / Execution Cycle #

A generic SUPER-CHIP emulator for the calculator variants should follow the following main loop:

For the calculator variants an adequate speed is 30 instructions per frame. At 64Hz this means that the interpreter executes about 1920 instructions per second, besides the limiting effect of DISPLAY WAIT in lores mode.

Modern SUPER-CHIP runs at 60Hz, and there is no display wait.

7 Reset Sequence & Program Loading #

The recommended initialization and loading of programs is as follows:

• Clear memory (all bytes set to 0)
• Copy the selected SUPER-CHIP small and big fonts into memory
• PC = 0x200
• I = 0
• All Vx = 0
• DT, ST = 0
• Select the initial display mode for the variant
• Clear screen (all pixels off)
• Binary image of SUPER-CHIP program is copied/loaded into memory starting at 0x200.

The actual order of these steps is flexible, as long as you keep memory clearing in front of the font initialization and program loading. Persistent flags should not be cleared by a normal program reset if you want to mimic the calculator behavior.

8 SUPER-CHIP Quirks #

Compared to classic CHIP-8, the calculator SUPER-CHIP variants make the following behaviors part of the variant:

• Timer rate - timers and frames run at 64Hz on the calculator variants.
• Execution speed - 15 instructions per frame is an adequate default for the calculator variants.
• Display wait - stop the instruction loop for the frame after drawing in lores mode.
• Mode switching - 00FE disables extended mode, 00FF enables extended mode.
• Bit operations (8xy1, 8xy2, 8xy3) - VF is left unchanged.
• Shift instructions (8xy6, 8xyE) - the source and destination register is Vx, and y is ignored.
• Offsetted jump instructions (Bxkk) - jumps to xkk + Vx, not to mmm + V0.
• Extended drawing (Dxy0) - draws 8×16 in lores on the calculator, and 16×16 in extended/hires mode.
• Index overflow (Fx1E) - incrementing I above 0xFFF ends the interpreter.
• Register load and store (Fx55, Fx65) - the effect on I depends on the SUPER-CHIP sub-variant.
• Persistent flags (Fx75, Fx85) - store/load up to eight registers in storage surviving interpreter exit.

Modern SUPER-CHIP intentionally changes some of these behaviors: 60Hz timing, screen clear on mode change, logical-pixel scrolling, 16×16 Dxy0 in lores, and no display wait.

TLDR: What is Different to CHIP-8? #

Okay, you know CHIP-8, but what’s different about SUPER-CHIP? Here are the differences collected at one place:

Common on all SCHIP Versions #

• Memory is 4k as on CHIP-8, but allows for 3583 bytes as the max size of a program (theoretically 3584 should fit, but it would crash).
• Framerate is 64 Hz instead of 60 Hz.
• An adequate IPF rate is 15 instructions per frame.
• Resolution can now be changed by switching to an extended mode with 128×64 pixels (leaving three columns at the right edge of the LCD unused on the actual calculator).
• As in CHIP-48, if extended mode is off, the display of the 64×32 interpreter screen is drawn as 2×2 LCD pixels per CHIP-8 pixel.
• There is a display wait if extended mode is off.
• 00FD exit the interpreter.
• 00FE disable extended mode (and switch to lores, 64×32)
• 00FF enable extended mode (and switch to hires, 128×64)
• 8xy1/8xy2/8xy3 do not reset VF but leave it unchanged.
• 8xy6/8xyE are only use Vx, so they do Vx >>= 1/Vx <<= 1 instead of Vx = Vy >> 1/Vx = Vy << 1 and y is ignored.
• Bmmm here is Bxkk and jumps to xkk + Vx, so the x nibble doubles as part of the 12 bit address and an index for the register to add.
• Dxy0 draws a graphics pattern from memory at I like CHIP-8 Dxyn, but with a size of 8×16 pixels in lores mode and 16×16 pixels in extended/hires mode (the pattern is orderd in rows, so first 8 pixels if first row, second 8 pixels of first row, first 8 pixels of second row and so on).
• Incrementing I above 0xFFF with Fx1E ends the interpreter.
• Fx75/Fx85 store/load registers from V0 to Vx to a persistent storage (x <= 7), the limit of at most 8 registers is based on th fact that the calculator had only persistent storage for that many (64 bits user flags, that survived exit of the interpreter).

Most generic SUPER-CHIP emulators do clear the screen on mode change. Also the detail of drawing lores as 2x2 doesn’t need to be emulated, if the screen is cleared on mode change, as no artifacts can be visible. It is needed though if one implements original “lores half-pixel” scrolling (see below).

Also generic emulators often draw 16×16 pixels on Dxy0 in lores too e.g., Octo is unable to draw 8×16. Ideally make it an option/quirk. As most SUPER-CHIP games use hires, there are very few programs making use of the 8×16 lores draw.

The Fx75/Fx85 instructions have no hard established way of persistence outside of the calculator, so they could be kept in a static array, surviving emulator resets, or in a global file, so they survive the end of the emulator process, and for the latter, the option is to save them in a ROM specific file or in a shared one. The shared file mimics the way the calculator worked more (as programs could basically “communicate” over them), but the per-ROM file allows for multiple games to store e.g. progress, and pick up even after a different ROM uses those opcodes.

Legacy SCHIP Drawing:
On the calculator, the actual lores 2×2-drawing routine works a bit unusual: It draws the pattern into the even display rows doubling the pixels, and collision detection works on any of those two “sub-pixels” of each doubled pixel (as it does no mode change clear the result from a previous hires content might lead to different results for each half pixel). Then it copies 32 hires pixels, starting from the hiresSpritePosX & 0x70 to the odd row (no XOR here, the 32 pixels will look the same as the ones in the even row, so really a copy). This can lead to changes in the odd rows outside the border of the actual drawn pattern.

This is only relevant for the combination of a mode change from hires to lores without clearing the screen, as only that way and artifacts can be visible. No known-to-me game or non-test program makes use of this, so emulating this is more of a fun historic challenge than solving a real problem.

Also it doesn’t influence the strange SCHIP collision behavior, as that VF > 1 result is only happening in hires/extended mode.

Regular Font Data (4x5) #

The regular or small font of SUPER-CHIP is at address 0x0000 and made of this patterns (same as CHIP-48):

It’s made up of these 16 characters:

The data for easy use in an emulator:

    0xF0, 0x90, 0x90, 0x90, 0xF0,  // 0
    0x20, 0x60, 0x20, 0x20, 0x70,  // 1
    0xF0, 0x10, 0xF0, 0x80, 0xF0,  // 2
    0xF0, 0x10, 0xF0, 0x10, 0xF0,  // 3
    0x90, 0x90, 0xF0, 0x10, 0x10,  // 4
    0xF0, 0x80, 0xF0, 0x10, 0xF0,  // 5
    0xF0, 0x80, 0xF0, 0x90, 0xF0,  // 6
    0xF0, 0x10, 0x20, 0x40, 0x40,  // 7
    0xF0, 0x90, 0xF0, 0x90, 0xF0,  // 8
    0xF0, 0x90, 0xF0, 0x10, 0xF0,  // 9
    0xF0, 0x90, 0xF0, 0x90, 0x90,  // A
    0xE0, 0x90, 0xE0, 0x90, 0xE0,  // B
    0xF0, 0x80, 0x80, 0x80, 0xF0,  // C
    0xE0, 0x90, 0x90, 0x90, 0xE0,  // D
    0xF0, 0x80, 0xF0, 0x80, 0xF0,  // E
    0xF0, 0x80, 0xF0, 0x80, 0x80   // F

SUPER-CHIP v1.0 (BETA) #

• Fx29 will set I to an address pointing to big font (8×10) digits for Vx > 15 && Vx < 26 and pixel garbage for the rest.
• Fx55/Fx65 increment I by x instead of x+1.

Big Font Data (8×10) #

    0x3c, 0x7e, 0xc3, 0xc3, 0xc3, 0xc3, 0xc3, 0xc3, 0x7e, 0x3c, // big 0
    0x18, 0x38, 0x58, 0x18, 0x18, 0x18, 0x18, 0x18, 0x18, 0x3c, // big 1
    0x3e, 0x7f, 0xc3, 0x06, 0x0c, 0x18, 0x30, 0x60, 0xff, 0xff, // big 2
    0x3c, 0x7e, 0xc3, 0x03, 0x0e, 0x0e, 0x03, 0xc3, 0x7e, 0x3c, // big 3
    0x06, 0x0e, 0x1e, 0x36, 0x66, 0xc6, 0xff, 0xff, 0x06, 0x06, // big 4
    0xff, 0xff, 0xc0, 0xc0, 0xfc, 0xfe, 0x03, 0xc3, 0x7e, 0x3c, // big 5
    0x3e, 0x7c, 0xc0, 0xc0, 0xfc, 0xfe, 0xc3, 0xc3, 0x7e, 0x3c, // big 6
    0xff, 0xff, 0x03, 0x06, 0x0c, 0x18, 0x30, 0x60, 0x60, 0x60, // big 7
    0x3c, 0x7e, 0xc3, 0xc3, 0x7e, 0x7e, 0xc3, 0xc3, 0x7e, 0x3c, // big 8
    0x3c, 0x7e, 0xc3, 0xc3, 0x7f, 0x3f, 0x03, 0x03, 0x3e, 0x7c  // big 9

SUPER-CHIP v1.0 #

• Fx29 behaves like in CHIP-8.
• A new Fx30 will set I to an address pointing to big font digits for Vx < 10 and pixel garbage for the rest.
• Fx55/Fx65 increment I by x instead of x+1.

Big Font Data (8×10) #

Same as the BETA one (above).

SUPER-CHIP v1.1 #

• A new 00Cn instruction will scroll the screen down by n pixels, the calculator implementation will always scroll n display-pixels, not logical pixels, so scrolling by 4 will scroll 4 128×64-resolution pixels in extended mode, and 2 64×32-resolution pixels in lores mode. Be aware that 00C0 is not a valid instruction and will end the interpreter.
• The new 00FB and 00FC instructions will scroll the screen right (00FB) or left (00FC) by four display resolution pixels (see above at 00Cn for explanation).
• Fx29 behaves like in CHIP-8.
• A new Fx30 will set I to an address pointing to big font digits for Vx < 10 and pixel garbage for the rest.
• Fx55/Fx65 don’t change I at all.
• Dxy0/Dxyn in hires on the calculator has the special collision behavior that VF contains the number of rows wher a collision happened plus the numbers of rows clipped at the bottom border.

The special collision behavior is not implemented in Octo, or most of the generic SUPER-CHIP emulators, and it can trip some programs. Best make it an option/quirk and allow regular collision reporting via 0/1 in VF.

Big Font Data (8×10) #

    0x3C, 0x7E, 0xE7, 0xC3, 0xC3, 0xC3, 0xC3, 0xE7, 0x7E, 0x3C, // big 0
    0x18, 0x38, 0x58, 0x18, 0x18, 0x18, 0x18, 0x18, 0x18, 0x3C, // big 1
    0x3E, 0x7F, 0xC3, 0x06, 0x0C, 0x18, 0x30, 0x60, 0xFF, 0xFF, // big 2
    0x3C, 0x7E, 0xC3, 0x03, 0x0E, 0x0E, 0x03, 0xC3, 0x7E, 0x3C, // big 3
    0x06, 0x0E, 0x1E, 0x36, 0x66, 0xC6, 0xFF, 0xFF, 0x06, 0x06, // big 4
    0xFF, 0xFF, 0xC0, 0xC0, 0xFC, 0xFE, 0x03, 0xC3, 0x7E, 0x3C, // big 5
    0x3E, 0x7C, 0xE0, 0xC0, 0xFC, 0xFE, 0xC3, 0xC3, 0x7E, 0x3C, // big 6
    0xFF, 0xFF, 0x03, 0x06, 0x0C, 0x18, 0x30, 0x60, 0x60, 0x60, // big 7
    0x3C, 0x7E, 0xC3, 0xC3, 0x7E, 0x7E, 0xC3, 0xC3, 0x7E, 0x3C, // big 8
    0x3C, 0x7E, 0xC3, 0xC3, 0x7F, 0x3F, 0x03, 0x03, 0x3E, 0x7C  // big 9

Modern SUPER-CHIP #

There is a new variant of SUPER-CHIP we now call “Modern SUPER-CHIP”, that is based on the SUPER-CHIP behavior of the Octo implementation. The idea is to leave out the most exotic parts of the original SUPER-CHIP and simplify the implementation. The differences to SUPER-CHIP v1.1 are:

• Framerate and timer frequency are simply 60Hz
• Mode changes (enabling extended or hires mode or disabling extended or hires mode) always clear the screen.
• The 00Cn instruction scrolls the screen down by n logical pixels, so no half pixel scrolling in lores mode.
• The 00FB and 00FC instructions scroll the screen right (00FB) or left (00FC) by four logical pixels.
• The forced screen clear and no half-pixel-scroll allow to not care about legacy SCHIP drawing, as the artifacts possible by it can not happen.
• The Dxy0 always draws 16x16 pixels, even when not in extended (hires) mode.
• There is no DISPLAY WAIT even in lores mode (so when extended mode is off).

Acknowledgments #

• Special thanks to Chromatophore for his analysis of the specifics of SUPER-CHIP in his ⎋ HP48-Superchip project. This helped me a lot to understand some oddities of the HP-48SX based implementations.
• Thanks to Tobias V. I. Langhoff for his page about ⎋ Running CHIP-8 on a HP 48 calculator as it was invaluable to get me started again on loading software into the calculator and trying things out for myself.
