XO-CHIP: Technical Reference #

(A compact, implementation-level description of XO-CHIP, suitable for both program authors and emulator writers that want to implement it as its own variant instead of as SUPER-CHIP with a few more opcodes.)

You know CHIP-8 and are only interested in a compact description of the differences? Jump to the TLDR section.

1 Overview #

XO-CHIP is a modern CHIP-8 extension introduced by Octo. It keeps the general CHIP-8 programming model, but adds a 64k address space, a simplified SUPER-CHIP-like 128×64 display mode, two drawing bitplanes, range load/store instructions, persistent flag registers, and a simple pattern based audio system.

The SUPER-CHIP part of XO-CHIP is intentionally the simplified/modern form, not the original calculator behavior. So a generic XO-CHIP implementation should not inherit the more unusual legacy SUPER-CHIP details like lores half-pixel scrolling, lores 8×16 Dxy0, or display wait.

XO-CHIP defines a virtual machine with:

• 64kB of addressable memory (0x0000-0xFFFF).
• Sixteen 8-bit general-purpose registers V0...VF.
• One 16-bit index register I as an index into the ram.
• Two 8-bit timers (DT, the delay timer, ST the sound timer) that count down at 60Hz.
• A two-plane display that can switch between 64×32 lores and 128×64 extended/hires mode.
• A hexadecimal keypad with 16 keys (0-F).
• A 16-byte audio pattern buffer and a pitch register.
• Persistent flag storage for all sixteen data registers.

All XO-CHIP programs are loaded at memory location 0x200, where the interpreter begins execution after a reset.

2 Virtual Machine Model #

2.1 State #

For the definition of the state, the following table uses the types:

• uint8 = 8-bit unsigned integer
• uint16 = 16-bit unsigned integer
• bool = true/false value

Choose the types that match this best for your chosen language.

The XO-CHIP VM/interpreter has the following state:

Stack pointer SP and program counter PC are internal registers of the interpreter, and in-accessible to an XO-CHIP program. They should be modeled as 16-bit values, as both sequential execution and the index register can reach beyond the classic 4k range.

2.2 Memory Layout #

A generic XO-CHIP implementation has 64k ram organized in bytes with a memory layout like this:

0x0000-0x004F   built-in small font
0x0050-0x00EF   built-in big font
0x00F0-0x01FF   unused
0x0200-0xFFFF   Program / working RAM

This allows program images up to 65024 bytes when loaded at 0x200. The classic jump and call instructions still only carry 12-bit addresses though, so code that wants to move control flow around freely is still naturally limited to the lower 4k address range. The extended space is mainly useful for data, graphics, audio patterns, tables, and sequential code that is reached without needing a high-address jump target.

Do not mask PC or I to 12 bits in an XO-CHIP implementation. F000 exists specifically to allow I to point anywhere in the 64k address space.

2.3 Timers #

• Both timers are unsigned 8-bit counters.
• When set to a non-zero value they decrement automatically at 60 Hz.

XO-CHIP does not define a fixed instruction rate. Octo defaults to 20 instructions per frame, but XO-CHIP programs are typically delay-timer paced. For a generic emulator, a higher default like 500 or 1000 instructions per frame is a reasonable option.

2.4 Sound #

XO-CHIP keeps the classic sound timer, but replaces the plain “some beep while ST > 0” model with a small pattern based audio system.

F002 copies 16 bytes from memory at I into an internal audio pattern buffer. Later changes to memory do not change the active pattern until F002 is executed again. The initial pattern buffer contents are implementation defined, so programs that use XO-CHIP audio should initialize it explicitly.

The pitch register controls the playback rate of the pattern buffer. Fx3A sets the pitch from Vx using:

4000 * 2^((Vx - 64) / 48)

The pitch register is initialized to 4000Hz. The perceived tone also depends on the pattern data itself, as the buffer is treated as 1-bit sample data.

The playback position should only reset when the sound timer reaches 0 or is directly set to 0. Repeatedly writing a non-zero value to ST while it is already active should keep the pattern playing continuously.

2.5 Graphics #

XO-CHIP has two drawing bitplanes. Each plane is monochrome, but the two planes are shown together, giving four possible pixel values: background, plane 1 only, plane 2 only, and both planes together. The actual colors are up to the implementation.

Fx01 selects which planes are affected by clear, scroll, and draw instructions:

• plane 0 selects no planes.
• plane 1 selects the first plane.
• plane 2 selects the second plane.
• plane 3 selects both planes.

The default selected plane is 1, so normal CHIP-8 and SUPER-CHIP drawing behavior works without using Fx01.

Dxyn draws 8×n pixel graphics. Dxy0 draws 16×16 pixel graphics in both lores and extended/hires mode. When both planes are selected, drawing consumes twice as many bytes: first the sprite data for plane 1, then the same amount of sprite data for plane 2. VF is set if a collision happens on any selected plane.

Mode changes with 00FE and 00FF clear the screen. There is no implicit display wait in either mode.

The scroll instructions operate on the selected plane(s) and scroll by pixels of the current resolution:

• 00Cn scrolls down by n pixels. 00C0 does nothing.
• 00Dn scrolls up by n pixels. 00D0 does nothing.
• 00FB scrolls right by four pixels.
• 00FC scrolls left by four pixels.

2.6 Font Set #

The regular or small font of XO-CHIP is at address 0x0000 and made of this patterns (same as CHIP-48):

It’s made up of these 16 characters:

The data for easy use in an emulator:

    0xF0, 0x90, 0x90, 0x90, 0xF0,  // 0
    0x20, 0x60, 0x20, 0x20, 0x70,  // 1
    0xF0, 0x10, 0xF0, 0x80, 0xF0,  // 2
    0xF0, 0x10, 0xF0, 0x10, 0xF0,  // 3
    0x90, 0x90, 0xF0, 0x10, 0x10,  // 4
    0xF0, 0x80, 0xF0, 0x10, 0xF0,  // 5
    0xF0, 0x80, 0xF0, 0x90, 0xF0,  // 6
    0xF0, 0x10, 0x20, 0x40, 0x40,  // 7
    0xF0, 0x90, 0xF0, 0x90, 0xF0,  // 8
    0xF0, 0x90, 0xF0, 0x10, 0xF0,  // 9
    0xF0, 0x90, 0xF0, 0x90, 0x90,  // A
    0xE0, 0x90, 0xE0, 0x90, 0xE0,  // B
    0xF0, 0x80, 0x80, 0x80, 0xF0,  // C
    0xE0, 0x90, 0x90, 0x90, 0xE0,  // D
    0xF0, 0x80, 0xF0, 0x80, 0xF0,  // E
    0xF0, 0x80, 0xF0, 0x80, 0x80   // F

The big font is at address 0x0050 and consists of 8×10 pixel hexadecimal digits:

    0xFF, 0xFF, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xFF, 0xFF, // 0
    0x18, 0x78, 0x78, 0x18, 0x18, 0x18, 0x18, 0x18, 0xFF, 0xFF, // 1
    0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, // 2
    0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, // 3
    0xC3, 0xC3, 0xC3, 0xC3, 0xFF, 0xFF, 0x03, 0x03, 0x03, 0x03, // 4
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, // 5
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, // 6
    0xFF, 0xFF, 0x03, 0x03, 0x06, 0x0C, 0x18, 0x18, 0x18, 0x18, // 7
    0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, // 8
    0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, // 9
    0x7E, 0xFF, 0xC3, 0xC3, 0xC3, 0xFF, 0xFF, 0xC3, 0xC3, 0xC3, // A
    0xFC, 0xFC, 0xC3, 0xC3, 0xFC, 0xFC, 0xC3, 0xC3, 0xFC, 0xFC, // B
    0x3C, 0xFF, 0xC3, 0xC0, 0xC0, 0xC0, 0xC0, 0xC3, 0xFF, 0x3C, // C
    0xFC, 0xFE, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xFE, 0xFC, // D
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, // E
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0xC0, 0xC0, 0xC0, 0xC0  // F

NOTE:
Load the fonts into memory on every reset (as the previous program run could have modified them).

2.7 Input (Hex Keypad) #

The keypad consists of 16 keys labeled 0-F. Key states are queried by opcodes Ex9E, ExA1, and Fx0A.

The opcodes Ex9E, ExA1, Fx29, and Fx30 only use the lower 4 bits of Vx. So a value greater than 15 is not an error here, the upper 4 bits are ignored.

3 Instruction Format #

• Most instructions are 16 bit (2 bytes), stored big-endian (high byte first).
• F000 is a 32 bit (4 byte) instruction: the F000 header is followed by a 16-bit big-endian address.
• The most significant nibble determines the primary opcode class; the remaining nibbles supply operands or further opcode distinction.

For this reference the naming convention is following the one used in the original CHIP-8 documentation, but using lowercase letters for better distinction from the opcode defining nibbles:

After fetch, the PC normally is incremented by 2 and jump-, branch-, or skip-instructions modify it explicitly. For F000, the PC has to advance by 4.

Conditional skip instructions (3xkk, 4xkk, 5xy0, 9xy0, Ex9E, ExA1) skip the whole 4-byte F000 addr instruction if it is next, not only its first two bytes.

4 XO-CHIP Opcode Set #

The table below enumerates the XO-CHIP opcode set. It includes the simplified SUPER-CHIP-style instructions that XO-CHIP inherits, plus the XO-CHIP additions.

NOTE:
5xy2 and 5xy3 are useful as non-incrementing alternatives to Fx55 and Fx65. They also allow reversed register order, as the registers are processed in the order encoded by x and y.

5 Main Loop / Execution Cycle #

A generic XO-CHIP emulator should follow the following main loop:

XO-CHIP has no implicit display wait. If you expose a display-wait quirk for compatibility with other variants, it should not be enabled for normal XO-CHIP behavior. As XO-CHIP games typically use the delay timer for timing, it’s useful to use a higher default IPF of maybe 500-1000 instructions per frame.

6 Reset Sequence & Program Loading #

The recommended initialization and loading of programs is as follows:

• Clear memory (all bytes set to 0)
• Copy the XO-CHIP small and big fonts into memory
• PC = 0x200
• I = 0
• All Vx = 0
• DT, ST = 0
• selectedPlanes = 1
• Initialize the audio pitch to 4000Hz
• Initialize or clear the audio pattern buffer
• Select lores mode
• Clear both display planes
• Binary image of XO-CHIP program is copied/loaded into memory starting at 0x200.

The actual order of these steps is flexible, as long as you keep memory clearing in front of the font initialization and program loading. Persistent flags may be kept across resets or emulator runs, depending on the persistence model you choose.

7 XO-CHIP Quirks & Specifics #

Compared to classic CHIP-8, XO-CHIP makes the following behaviors part of the variant:

• Memory size - 64k memory with 16-bit PC and I.
• Timer rate - timers and frames run at 60Hz.
• No display wait - drawing does not implicitly stop the instruction loop for the frame.
• Mode switching - 00FE disables extended mode, 00FF enables extended mode, and mode changes clear the screen.
• Scrolling - 00Cn, 00Dn, 00FB, and 00FC scroll selected planes by pixels of the current resolution.
• Bit operations (8xy1, 8xy2, 8xy3) - VF is left unchanged.
• Shift instructions (8xy6, 8xyE) - the source and destination register is Vx, and y is ignored.
• Offsetted jump instructions (Bxkk) - jumps to xkk + Vx, not to mmm + V0.
• Range load/store (5xy2, 5xy3) - process registers from Vx to Vy in the encoded order and do not change I.
• Extended drawing (Dxy0) - always draws 16×16 pixels.
• Long load (F000) - loads a full 16-bit address into I, and skip instructions skip it as a 4-byte instruction.
• Bitplanes (Fx01) - clear, scroll, and draw affect only selected planes.
• Audio pattern (F002, Fx3A) - audio uses a copied 16-byte pattern buffer and a pitch register.
• Register load and store (Fx55, Fx65) - I is incremented by x+1.
• Persistent flags (Fx75, Fx85) - store/load up to all sixteen registers.

TLDR: What is Different to CHIP-8? #

First of all, why to CHIP-8 and not SUPER-CHIP? Well, the SUPER-CHIP part in XO-CHIP is a simplified version of SUPER-CHIP, even with all the options defined by the reference implementation Octo it can not be configured to fully emulate the original SUPER-CHIP. So listing the changes to CHIP-8 lets out the quirky parts of SUPER-CHIP that are not part of XO-CHIP anyway.

Okay, with that out of the way, you know CHIP-8, but what’s different about CHIP-48? Here are the differences collected at one place:

• Memory is 64k (65536 bytes), and allows for program sizes up to 65024 bytes.
• As there are no jump/call changes, active code size is still limited to the lower 3584 bytes.
• Framerate is 60 Hz (so not derived from SUPER-CHIP).
• XO-CHIP doesn’t define an execution speed and Octo defaults to 20 ipf or instructions per frame, but XO-CHIP programs are typically delay-timer paced, so a good default is 500 or 1000 ipf imho.
• Resolution can be changed by switching to an extended mode with 128×64 pixels.
• There is no way to change resolution without clearing the display, so how one renders the lores mode (2×2 pixels in the hires gfx or scaled 64×32 texture) is up to the emulator.
• There no implicit display wait in any mode (still a supported quirk).
• 00Cn will scroll the screen down by n pixels of the current resolution. 00C0 does nothing.
• 00Dn will scroll the screen up by n pixels of the current resolution. 00D0 does nothing.
• 00FB and 00FC instructions will scroll the screen right (00FB) or left (00FC) by four pixels.
• 00FD exit the interpreter.
• 00FE disable extended mode (and switch to lores, 64×32)
• 00FF enable extended mode (and switch to hires, 128×64)
• 5xy2 writes the registers from Vx to Vy to memory pointed to by I, in the order given, so if y < x the registers are written in reverse order.
• 5xy3 reads the registers from Vx to Vy from memory pointed to by I, in the order given, so if y < x the registers are read in reverse order.
• 8xy1/8xy2/8xy3 do not reset VF but leave it unchanged.
• 8xy6/8xyE are only use Vx, so they do Vx >>= 1/Vx <<= 1 instead of Vx = Vy >> 1/Vx = Vy << 1 and y is ignored.
• Bmmm here is Bxkk and jumps to xkk + Vx.
• Dxy0 draws a graphics pattern from memory at I like CHIP-8 Dxyn, but with a size of 16×16 pixels independant of the resolution/mode (the pattern is orderd in rows, so first 8 pixels if first row, second 8 pixels of first row, first 8 pixels of second row and so on).
• F000 will load the following 2 bytes (high byte then low byte) as 16 bit address into I, so this is a 4 byte instruction.
• Fx01 selects bit planes to draw on when drawing with Dxy0/Dxyn (only two bit or four colors in the original, but many implementations support 4 bit for 16 colors)
• Fx02 loads 16 bytes audio pattern pointed to by I into audio pattern buffer. I is not incremented.
• Fx30 will set I to an address pointing to 8x10 hexadecimal big font digits for Vx & 0xF. They are stored in memory starting at 0x50 (50h).
• Fx3A sets audio pitch for a audio pattern playback rate of 4000*2^((vX-64)/48) Hz.
• Fx55/Fx65 increment I by x+1 as opposed to SUPER-CHIP.
• Fx75/Fx85 store/load registers from V0 to Vx to a persistent storage.

Regular Font Data (4x5) #

The regular or small font of SUPER-CHIP is at address 0x0000 and made of this patterns (same as CHIP-48):

It’s made up of these 16 characters:

The data for easy use in an emulator:

    0xF0, 0x90, 0x90, 0x90, 0xF0,  // 0
    0x20, 0x60, 0x20, 0x20, 0x70,  // 1
    0xF0, 0x10, 0xF0, 0x80, 0xF0,  // 2
    0xF0, 0x10, 0xF0, 0x10, 0xF0,  // 3
    0x90, 0x90, 0xF0, 0x10, 0x10,  // 4
    0xF0, 0x80, 0xF0, 0x10, 0xF0,  // 5
    0xF0, 0x80, 0xF0, 0x90, 0xF0,  // 6
    0xF0, 0x10, 0x20, 0x40, 0x40,  // 7
    0xF0, 0x90, 0xF0, 0x90, 0xF0,  // 8
    0xF0, 0x90, 0xF0, 0x10, 0xF0,  // 9
    0xF0, 0x90, 0xF0, 0x90, 0x90,  // A
    0xE0, 0x90, 0xE0, 0x90, 0xE0,  // B
    0xF0, 0x80, 0x80, 0x80, 0xF0,  // C
    0xE0, 0x90, 0x90, 0x90, 0xE0,  // D
    0xF0, 0x80, 0xF0, 0x80, 0xF0,  // E
    0xF0, 0x80, 0xF0, 0x80, 0x80   // F

Big Font Data (8×10) #

    0xFF, 0xFF, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xFF, 0xFF, // 0
    0x18, 0x78, 0x78, 0x18, 0x18, 0x18, 0x18, 0x18, 0xFF, 0xFF, // 1
    0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, // 2
    0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, // 3
    0xC3, 0xC3, 0xC3, 0xC3, 0xFF, 0xFF, 0x03, 0x03, 0x03, 0x03, // 4
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, // 5
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, // 6
    0xFF, 0xFF, 0x03, 0x03, 0x06, 0x0C, 0x18, 0x18, 0x18, 0x18, // 7
    0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, // 8
    0xFF, 0xFF, 0xC3, 0xC3, 0xFF, 0xFF, 0x03, 0x03, 0xFF, 0xFF, // 9
    0x7E, 0xFF, 0xC3, 0xC3, 0xC3, 0xFF, 0xFF, 0xC3, 0xC3, 0xC3, // A
    0xFC, 0xFC, 0xC3, 0xC3, 0xFC, 0xFC, 0xC3, 0xC3, 0xFC, 0xFC, // B
    0x3C, 0xFF, 0xC3, 0xC0, 0xC0, 0xC0, 0xC0, 0xC3, 0xFF, 0x3C, // C
    0xFC, 0xFE, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xC3, 0xFE, 0xFC, // D
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, // E
    0xFF, 0xFF, 0xC0, 0xC0, 0xFF, 0xFF, 0xC0, 0xC0, 0xC0, 0xC0  // F
